Key Advantages:

• Unmatched Power: Our most powerful portable X-ray system, ensuring excellent image penetration and quality.
• Military-Grade Design: Initially developed for demanding military applications, guaranteeing rugged durability and dependable performance in any environment.
• Compact & High-Power: A general-purpose system that delivers robust imaging capabilities within a compact, portable footprint.
• Universal Input Power: Features Power Factor Correction, allowing for versatile operation with any 100 - 240V input, ensuring consistent performance regardless of power source.
• Exceptional Portability: Weighing only 110 lbs, it offers unparalleled ease of transport and positioning.

Specifications & Performance:

• Radiographic Applications: Versatile for use in a wide array of settings including hospitals, medical centers, clinics, sport complexes, nursing homes, home health care, correctional facilities, and military operations.
• Generator Type: High-frequency Resonant Inverter, Microprocessor controlled, for precise and stable X-ray generation.
• kVp Range: 40 - 120 kVp, adjustable in precise 1 kVp steps, providing optimal penetration for various tissue densities, especially for extremity imaging.
• mA Range: Selectable from 12.5 – 60 mA, with dynamic mA adjustment dependent on kVp or time settings for optimized output.
• mAs Range: 0.125 - 200 mAs (Optimum Range), ensuring high-quality soft tissue and bone resolution.
• Exposure Time: Offers 96 distinct steps, allowing for highly accurate technique settings and fine-tuned exposures.
• X-Ray Tube: Stationary anode with a 15° target angle and a 1.2 mm focal spot (fs). Boasts 30,000 Heat Unit Storage, providing superior image quality and excellent heat dissipation for sustained use.
• Collimator: Features a 200° rotation range with a high-output LED lamp and laser indicators for accurate and efficient field definition.
• Exposure Switch: 2-position (Prep / X-ray) design with a 15-foot cable for operator safety and flexibility.
• Mechanical Stand: Constructed from welded aluminum, ensuring a robust, stable, and lightweight support structure for the X-ray unit.
